Elongated Glass IR Panel with a carbon heating element, frameless glass front and white aluminium back. IP65 rated, suited to larger bathrooms and living spaces.

Carbon heating element for fast, efficient far infrared heat
Frameless tempered glass front with aluminium back panel
Premium white aluminium back coating
IP65 rated - fully protected against water jets from any direction
98% energy transfer efficiency
20 year expected service life

Size:550 x 600mm
Coverage:3.5-4m²

Size:600 x 700mm
Coverage:6.5-7.5m²

Size:550 x 1100mm
Coverage:7.5-8.5m²

Size:300 x 1800mm
Coverage:8.5-9.5m²

Size:600 x 1200mm
Coverage:10-12m²
| Heating Element | Carbon |
|---|---|
| Construction | Frameless Glass |
| Material | Aluminium |
| Coating | White Aluminium Back |
| Dimensions (L x W x D) | 550 x 1100 x 25mm |
| Weight | 11.75kg |
| Rated Power | 500 Watt |
| Current Draw | 2.17 Amps |
| Room Coverage | 7.5 - 8.5m² |
| Surface Temperature | 90/110°C |
| Operating Voltage | 110/240Vac |
| Connection | 1.9 metre Cable |
| Installation Type | Wall Mount |
| Service Life | 20 Years |
| IP Rating | IP65 |
| Certifications | CE, RoHS, UKCA, EMC |
| Warranty | 5 Years |
Heating Element
Carbon
Construction
Frameless Glass
Material
Aluminium
Coating
White Aluminium Back
Dimensions (L x W x D)
550 x 1100 x 25mm
Weight
11.75kg
Rated Power
500 Watt
Current Draw
2.17 Amps
Room Coverage
7.5 - 8.5m²
Surface Temperature
90/110°C
Operating Voltage
110/240Vac
Connection
1.9 metre Cable
Installation Type
Wall Mount
Service Life
20 Years
IP Rating
IP65
Certifications
CE, RoHS, UKCA, EMC
Warranty
5 Years
The Yandiya IH500-G is our elongated Glass IR Panel, measuring 550 x 1100mm to deliver a larger heating surface while keeping a slim, discreet profile. It uses the same carbon heating element and frameless tempered glass front with white aluminium back as the rest of the range.
The IP65 rating means the IH500-G is fully protected against water jets from any direction, so it can be installed with confidence in bathrooms and other wet areas. Energy transfer of 98% ensures minimal waste and low running costs.
With a 20 year expected service life and 5 year manufacturer warranty, the IH500-G connects via a 1.9 metre cable and is installed via simple wall mounting.
5 Year Warranty
Manufacturer Guarantee
Full 5-year manufacturer warranty covering all manufacturing defects on the heating element and glass surface.
Visit our Downloads page for the complete range of technical documents, certificates, and resources.
